Husqvarna YTH1848XP User Manual

5
UNASSEMBLED PARTS
(1) Large Flat
Washer
Steering
Wheel Insert
Steering
Extension
Shaft
Steering
Sleeve
Steering Wheel
Steering
Wheel
Adapter
(1) Knob
(1) Washer
17/32 x 1-3/16 x 12 Gauge
Seat
Mower
Gauge Wheels
(4) Washers
3/8 x 3/4 x 14 Ga.
(4) Wheels
(4) Adjusting Bars
(4) Retainer Springs
(double loop)
(4) Clevis Pins
(4) Locknuts 3/8-16
(4) Shoulder Bolts
Nose Roller
(2) Hex Bolts
5/16 x 18 x 1
(2) Locknuts
5/16-18
(1)Front Plate
Assembly
(5) Retainer Springs
(double loop)
(2) Retainer Springs
(single loop)
(2)Flanged
Pins
(2) Keys
Keys
Slope Sheet
(1) Oil Drain Tube
For Future Use
Nose Roller
Brackets
Rod
Retainer
Spring
(1) Hex Bolt 1/4-28 x 1-1/4
(1) Locknut 1/4-28
(1) Locknut 1/2-20

Husqvarna YTH1848XP Specifications

General

Manufacturer	Husqvarna
Model	YTH1848XP
Category	Lawn Mower
Cutting Width	48 inches
Engine Power	18 HP
Transmission Type	Hydrostatic
Warranty	3 years
Cutting Height	1.5 - 4 inches
