11
TRACTOR - - MODEL NO. YTH184T (96041030600), PRODUCT NO. 960 41 03-06
ENGINE
24
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 – – – – – – Engine Kawa Model No. FS541-CS51
(445366) (Order parts from engine
manufacturer.)
2 532 44 59-62 Muffler
9 532 19 43-20 Keeper Belt Engine
11 532 18 05-05 Clutch Electric
12 532 40 50-97 Pulley Engine
15 532 19 34-99 Tank Fuel 4.0
18 532 43 96-45 Cap Asm
20 532 41 21-65 Control Throttle
21 532 41 63-58 Screw #10 x 0.75 BOS Thread
22 532 19 15-96 Control Choke
28 532 14 21-58 Fuel Line
29 532 13 71-80 Spark Arrester Kit
37 532 12 34-87 Clamp Hose
41 532 12 61-97 Washer 1-1/2 OD x 15/32 ID x .250
42 810 04 07-00 Washer Lock 7/16
45 873 51 04-00 Nut Keps Hex 1/4-20 unc
62 532 43 40-17 Shield Heat Muffler
69 532 17 81-51 Gasket
70 532 42 47-65 Tube Exhaust LH
71 532 42 47-66 Tube Exhaust RH
81 532 14 84-56 Tube Drain Oil Easy
85 532 17 39-37 Bolt Hex 7/16-20 x 4 x Gr. 5-1.5
86 532 18 43-62 Nut Hex Flange Toplock M8-1.2
87 532 17 18-77 Bolt 5/16-18 unc x 3/4 w/Sems
90 817 00 06-16 Screw 3/8-16 x 1
92 817 12 06-16 Screw 3/8-16 x 1
To Next Page
