114443_1011 5-5

Instrument Panel

INDEX NO. PART NO. QTY. DESCRIPTION

1 112661 1 INSTRUMENT PANEL

2 603323 1 INSTRUMENT PANEL DECAL

3 114884 1 INSTRUMENT PANEL PLATE

114279 1 INSTRUMENT PANEL PLATE

4 064006 5 CS .312-18 X .625 HX G5

5 768523 12 FW .343 X .687 X .051/.080H

6 064329 10 CS .250-20 X .625 HX G5

7 768515 28 FW .281 X .625 X .051/.080H

8 602696 1 LIFT/LOWER DECAL

9 602923 1 CHOKE DECAL

10 034280 4 CS .312-18 X .750 HX G5

11 602844 1 GLOVE BOX

12 808477 10 1/4-20 THREAD NUTSERT

13 112665 1 SWITCH BOX

14 000331 2 WIRE TIE, SMALL/SHORT

15 808485 4 RIVET NUT, 5/16-18 THREAD

16 112670 1 INSTRUMENT PANEL

17 034272 3 NT .312-18 HX G5 ZNYC

NOTES:

1. When ordering the instrument panel, also order (1) 114884 or 114279,

(4) 808477, (4) 768515 and (4) 064329.

2. Mowers with serial numbers prior to 11080000 require 114279.

3. Mowers with serial numbers 11080000 and higher require 114884.
