HUSTLER 1500 User Manual

114443_1011 7-19
Traction Drive
INDEX NO. PART NO. QTY. DESCRIPTION
9 008193 8 NT .500-13 HX G5 ZNYC
10 767962 8 FW .531 X 1.063 X .090 SAE
11 602390 2 MOTOR
12 602256 8 CS .500-13 X 2.500 SQ G5
13 602606 2 HOSE CLAMP, 1.00
14 079210 2 FW .344 X 1.00 X .06 ZNYC
15 050161 2 CS .312-18 X 1.750 HX G5
16 033001 .25’ TRIM
17 748806 2 SEAL KIT–MOTOR
NOTES:
