114443_1011 7-23
Hydraulic Reel Drive
INDEX NO. PART NO. QTY. DESCRIPTION
1 114470 1 HYDRO PLATE
2 602727 3 CS .312-18X1.0 BHSK ZNYC
3 808485 3 RIVET NUT, 5/16-18 THREAD
4 602622 1 FTG, 6MSL RUN TEE BULKHEAD
5 602623 3 FTG, 8MSL STR BULKHEAD
6 603330 1 HOSE ASSY, FRONT TO REAR REEL SUPPLY
7 602624 3 FTG, 8MSL 90 BULKHEAD
8 602626 1 FTG, 8FSL SWVL UNION
9 603331 1 HOSE ASSY, FRONT TO REAR REEL CASE DRAIN
10 602625 1 FTG, 6MSL BRANCH T BULKHEAD
11 603329 1 HOSE ASSY, REEL SUPPLY FRONT CIRCUIT
12 602621 1 HOSE ASSY, REEL RETURN REEL CIRCUIT
13 602614 1 HOSE ASSY, PUMP-BLOCK REEL CIRCUIT
14 602617 1 HOSE ASSY, BLOCK FILTER REEL CIRCUIT
15 781534 3 FTG, STR-8MORB/8MSL
16 602615 1 HOSE ASSY, REAR REEL CASE DRAIN
17 748574 2 FTG, 6MORB/6MSL 90
18 602518 1 HOSE ASSY, REAR REEL RETURN
19 602517 1 HOSE ASSY, REAR REEL SUPPLY
20 781542 4 FTG, 90-8MORB/-8MORFS
21 602508 2 HOSE ASSY, RIGHT REEL SUPPLY
22 602510 1 HOSE ASSY, RIGHT REEL CASE DRAIN
23 792150 1 FTG, STR-6MORB/6MSL
24 602511 1 HOSE ASSY, LEFT REEL SUPPLY
25 602512 1 HOSE ASSY, LEFT REEL RETURN
26 602513 1 HOSE ASSY, LEFT REEL CASE DRAIN
27 602424 3 GEAR MOTOR, 12CC
28 603176 3 GM, .625 X .875 X 1.687 LONG
29 033001 6" FLEX TRIM
30 603289 1 GM, 2.25ID X 3.0OD X 2.5GD
31 060889 9 WIRE TIE, BIG/LONG
32 000430 1 WIRE TIE, SMALL/LONG
33 603402 3 SEAL KIT–GEAR MOTOR
NOTES:
1. Nuts included with respective bulkhead fittings.
