114443_1011 8-3
Seat
INDEX NO. PART NO. QTY. DESCRIPTION
1 602475 1 SEAT
2 797076 2 CS .437-20 X 1.00 HX G8 ZNYC
3 017129 4 FW .440 X 1.000 X .083 ZNY
4 601444 1 SEAT BELT
5 704635 2 NT .437-20 HX GR5 ZNYC
6 794610 1 SEAT BELT CROSS BAR
7 112102 1 SEAT PAN
8 034272 8 NT .312-18 HX G5 ZNYC
9 768523 13 FW .343 X .687 X .051/.080H
10 601241 1 GAS SPRING
11 036244 2 CS .375-16 X 1.000 HX G5
12 767954 11 FW .406 X .812 X .060 SAE
13 058776 2 NT .312-18 HXZY NL
14 112837 1 LATCH SUPPORT
15 601507 1 FW .406 X 1.000 X .06 NYLON
16 112836 1 LATCH HOOK
17 754358 1 SB .375 X .375 SH .312-18
18 064014 1 CS .312-18 X .875 HX G5 ZN
19 601059 1 KNOB
20 706176 1 NT .375-24 HX JAM ZN G5
21 601131 1 SPRING
22 112875 1 LATCH ROD
23 601650 2 VIBRATION MOUNT
24 034280 2 CS .312-18 X .750 HX G5
25 054502 2 NT .375-16 HX GRD 5 ZNY
26 086660 2 NT .375-16 HXZY NL
27 601815 1 BATTERY WARNINGS DECAL
28 793315 1 SEAT SWITCH
NOTES:
