114443_1011
8-5
ROPS
INDEX NO.
PART NO.
QTY.
DESCRIPTION
1
602476
1
ROPS (WITH DECALS)
2
058768
4
NT .625-11 HXZY NY
3
728030
8
FW .656 X 1.312 X .090 ZNY
4
047704
4
CS .625-11 X 3.500 HX G5
NOTES:
1.
Torque to 145 ft-lbs.
2.
Replace decals in the event they become worn or illegible.
86
88
Table of Contents
Table of Contents
3
General Information
5
Hardware Description Codes & Abbreviations
5
Service Literature
5
Options Available from Your Dealer
5
Using this Manual
5
Standard Torques
6
Frame
8
Footrest
10
Basket
12
Steering Wheel Support
16
Drive Linkage
18
Rear Steering Fork
24
Brake
26
Wheel & Tire
34
Wheel & Tire Breakdown
36
Battery
38
Instrument Panel
40
Glove Box Breakdown
44
Engine & Pump
46
Engine Service Parts
50
Fuel System
52
Hydraulic Reservoir
58
Hydraulic—Oil Cooler
62
Hydraulic—Oil Cooler Hoses
64
Hydraulic Valve Block
66
Manifold Block
68
Traction Drive
72
Hydraulic—Steering
76
Hydraulic Reel Drive
78
Hydraulic Reel Lift
80
Seat
84
Rops
86
Front Lift Arm
90
Rear Lift Arm
94
Numerical Index
99
