Item Part No. Qty Name
1 1 ENGINE, KAW FT691V
2 605317 1 HOSE, OIL DRAIN
3 604250 1 MUFFLER
4 000331 4 WIRE TIE, SMALL/SHORT
5 767954 4 FW 0.379X.82X.06 HD ZN
6 602580 4 CS .375-16X1.25HXG8ZYP85
7 036236 2 CS .312-18X1.000HXG5
8 768523 5 FW 0.343SAE
9 113946 1 CLUTCH ANCHOR
10 034272 2 NT .312-18HXG5
11 605490 1 PULLEY, ENG 4.58OP
12 712372 1 KEY 1/4 SQ X 0.66 LG(FS)
13 791251 1 HARNESS, CLUTCH PIGTAIL
Comments for Part Num. 791251
Pigtail was updated with epoxy to hold the wires steady. The wire sheath was also updated to a more flexible material.
14 601785K 1 CLUTCH KIT
15 602680 1 FW .453X1.12X.12 HRD ZN
16 601834 1 CS .437-20X3.25 HXG5 P85
17 033001 3" FLEXIBLE TRIM UNI-GRIP
18 720516 1 CS M8-1.25X16HX FL10.9
19 601841 1 BATTERY CABLE, NEG.
20 029876 1 LW .312 INTEXT ZN
21 601840 2 BATTERY CABLE, POS.
22 601982 2 CN .250-20X .150 MAX THK
23 030817 1 STARTER SOLENOID HW KIT
24 768515 4 FW 0.281SAE
25 064329 2 CS .250-20X0.625HXG5
26 044255 1 NT #10-32HXG5
27 024927 2 NT .250-20HXG5
28 771428 1 BATTERY CBL BOOT-RED(FS)
Engine, Muffler & Clutch (Multi-Page)
54" FasTrak Parts Manual - 940353EX - HTFSTS054KAWFT691VE
Mon Oct 12 02:36:08 UTC 2020 6-1
