1. Torque to 73 ft-lbs.
2. Torque to 30 ft-lbs.
3. Torque to 3–6 ft-lbs.
Item Part No. Qty Name
1 781567 3 NT .500-13NLG5
2 125847-4 1 BELT GUIDE, 4.00" IDLER
3 607428 1 FW 0.531 X 0.90 X 0.134
4 605467 3 DUST SHIELD
5 605512 1 4" IDLER PULLEY
6 607616 1 SPRING, DECK IDLER
7 121052 1 SLED, TENSIONER
8 604790 2 IDLER SLIDE, EXTRUDED
9 604251 7 NT .312-18 HXNL JAM G2ZN
10 604252 6 FW .340X.68X.04 ZN
11 604253 1 CB .50-13 X 2.00 STD ZN
12 705954 3 CS .500-13X1.25 HX G5 ZN
13 798603 3 FW .515X1.65X.12 HD ZN
14 604777 3 SPINDLE SPACER
15 604664 3 PULLEY, DECK DRIVE B-SEC
16 605504 3 SPACER, PULLEY
17 606362 3 DUST SHIELD
18 054502 12 NT .375-16HXG5
19 767954 24 FW 0.379X.82X.06 HD ZN
20 604486 2 FW .531X.812X.089 HD
21 607479 2 IDLER PULLEY, 5.00"
22 605465 1 BASE, IDLER PULLEY MOUNT
23 017129 1 FW .440X1.00X0.08 ZN
24 605508 1 FW .73X2.25X.31 ZN
25 607208 3 BLADE SPINDLE ASSY
26 005116 12 CS .375-16X1.38 HX G5 ZN
27 016253 7 CB .312-18X .750 FUL ZN
28 604254 2 CB .50-13 X 2.50 STD ZN
Deck Pulleys & Spindles
54" FasTrak Parts Manual - 940353EX - HTFSTS054KAWFT691VE
Mon Oct 12 02:36:14 UTC 2020 8-2
