Comments for Page: Frame
1. The frame includes the decal (605650).
2. The bumper (552922) includes the decal (602041).
Item Part No. Qty Name
1 552930 1 SVC, FRAME RFU
2 604307 3 MOUNT, PUSH BUTTON
3 000331 4 WIRE TIE, SMALL/SHORT
4 034272 4 NT .312-18HXG5
5 768523 4 FW 0.343SAE
6 015495 10 GREASE FITTING STRAIGHT
7 797910 4 CS .312-18x1.50FLT SH ZN
8 604888 2 GUIDE BLOCK, CARRIER
9 808493 6 RIVET NUT, 3/8-16 THREA
10 016899 6 NT .375-16 FLKG5
11 029629 8 CS .375-16X0.75 HXF G5ZN
12 054502 2 NT .375-16HXG5
13 767954 2 FW 0.379X.82X.06 HD ZN
14 121430 1 MUFFLER SHIELD
15 552922 1 SVC, BUMPER RFU
16 602041 1 DECAL, HOT
17 025395 2 CB .375-16 X 1.00 G5 ZN
18 605299 1 HAND GRIP, 7/8 I.D.
19 120370 1 W/A, FRAME LATCH
20 121108 1 SUPPORT, FUEL TANK W/A
21 605650 1 DECAL, TIP OVER DANGER
Not Shown 605547 1 WIRE HARNESS, KAWASAKI
Not Shown 602725 1 WIRE TIE,
Frame
54" Raptor Flip-Up Parts Manual - 940320 - HTHFUL054KAWFR691VA
Wed Nov 10 16:31:32 UTC 2021 3-1
