HUSTLER Raptor SD - Anti-Scalp Wheels

REV J 3-8 604856
When the wheel is mounted in the top hole, it is located .70”
(17.8mm) below the mower blades. This is the acceptable
setting for mowing at cutting heights of 1-1/2” (38.1mm) or
higher.
A. Anti-scalp wheel B. Adjusting holes
Figure 3-11
A
B
