302620 8/06 4-3
Battery Installation
NOTES:
1. When performing maintenance, disconnect battery ground cable and
black wire of harness and do not reconnect to battery until engine is
ready to be started (See owners manual).
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 058776 058776 2 NT .312-18 HX NL ZNYC
2 768523 768523 3 FW .343 X .687 X .051/.080 HD ZNYC
3 348417 348417 1 BATTERY CLAMP STRAP
4 785063 785063 1 POSITIVE BATTERY CABLE
5 771428 771428 1 RED BATTERY CABLE BOOT
6 055939 055939 2 CS .250-20 X .750 HX G5 ZNYC
7 029868 029868 4 LW .250 INT-EXT TOOTH ZNYC
8 024927 024927 2 NT .250-20 HX GR.5 ZNYC
9 740696 740696 1 BATTERY
10 034272 034272 2 NT .312-18 HX G5 ZNYC
11 768820 768820 1 BATTERY GROUND CABLE
12 034280 034280 1 CS .312-18 X .750 HX G5 ZNYC
13 029876 029876 1 LW .312 INT-EXT TOOTH ZNYC
14 779850 779850 2 CB .312-18 X 3.00 FUL ZN
To Next Page
