4-8 302620 8/06
NOTES:
1. Torque to 280-310 ft.-lbs. Included with wheel motor.
2. Torque brake assembly mounting bolts to 24 ft.-lbs.
3. 783118 used on left wheel.
4. 783126 used on right wheel.
5. Includes Item 1 (781260 Steering Bar Grip).
6. Used on mowers with serial numbers prior to 06071186.
