302620 8/06 5-15
Fuel System Installation
NOTES:
1. Torque to 20 ft.-lbs.
2. Supplied with new fuel tank.
ITEM NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY DESCRIPTION
1 784181 784181 2 FUEL TANK CAP
2 796318 796318 1 RIGHT SIDE FUEL TANK
3 796326 796326 1 LEFT SIDE FUEL TANK
4 791277 791277 2 FITTING, FUEL TANK 90°
5 745059 745059 1 3-WAY FUEL VALVE
6 000323 000323 6 CLIP
7 000331 000331 3 BLACK CABLE TIE
8 767954 767954 12 FW .406 X .812 X .060 SAE HD ZN
9 055822 055822 12 CS .375-16 X .75 HX G5 ZNYC
10 015818 015818 1 FUEL LINE 12.5” TOTAL
11 015818 015818 1 FUEL LINE 29" TOTAL
12 015818 015818 1 FUEL LINE 7.5” TOTAL KAWASAKI
015818 015818 1 FUEL LINE 22” TOTAL HONDA
To Next Page
