302620 8/06 6-3
Front Wheel Assembly
NOTES:
1. Apply grease to zerks (see owner’s manual).
2. Assemble with extended inner race down.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY DESCRIPTION
1 705954 705954 2 CS .500-13 X 1.25 HX G5 ZN
2 344267 344267 2 FW .510 X 2.15 X .187 SPL ZN
3 798603 798603 2 FW .515 X 1.65 X .125 HD ZY
4 263517 263517 2 BEARING DISC
5 784223 784223 4 BEARING W/O COLLAR
6 784603 784603 2 SPACER
7 045765 045765 2 FW 1.030 X 1.500 X.134 ZN
8 366625 366625 2 FORK
9 786731 786731 2 CS .750-10 X 8.00 HX GR5 ZYNC
10 025296 025296 4 FW .760 X 1.625 X .08 ZN
11 061101 061101 2 NT .750-10 HX NL ZN
12 786061 786061 2 WHEEL & TIRE ASSY
795245 N/A 2 OPTIONAL SEMI-PNEUMATIC TIRE/WHEEL ASSEMBLY
