114565_0112 6-19
Catcher Frame
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 603225 1 LID
2 603419 1 CATCHER DECAL
3 056077 7 CS .250-20 X 1.000 HX G5
4 768515 14 FW .281 X .625 X .051/.080H
5 603675 2 LATCH
6 080291 6 CS 10-24 X 1.500 HX ZNYC
7 704932 6 FW .219 X .500 X .048 ZNYC
8 059832 7 NT #10-24 HX NL ZN
9 603398 20 RIVET
10 603678 8 CAP NUT
11 603332 8 CLIP
12 114249 2 SPRING LID PIN
13 603333 2 SB .375 X 1.25 SH .312-18
14 603353 1 SCREEN
15 115146 1 BACK RIB BRACKET
16 068551 7 NT .250-20 HXZY NL
17 115147 2 SIDE RIB BRACKET
18 603400 8 FW .188" X .50" X .060
19 603214 1 INLET TUBE
20 058776 7 NT .312-18 HXZY NL
21 768523 16 FW .343 X .687 X .051/.080H
22 060723 1 MS #10-24 X .500 TH SL
23 602830 1 SNAP FASTENER
24 050161 3 CS .312-18 X 1.750 HX G5
25 603285 4 LID HINGE SPRING
26 114248 2 LID HINGE PIN
27 115048 2 LATCH BRACKET
28 034280 4 CS .312-18 X .750 HX G5
29 036244 2 CS .375-16 X 1.000 HX G5
30 767954 8 FW .406 X .812 X .060 SAE
31 113640 1 3 BAG CATCHER FRAME
32 603418 1 LID SEAL
33 114118 1 LID ADJUST BRACKET
34 054502 2 NT .375-16 HX GRD 5 ZNY
35 034272 2 NT .312-18 HX G5 ZNYC
