Item Part No. Qty Name
1 602916 2 CAP, 3.5" RATCHETING GAS
2 602989 1 RS FUEL TANK ASSEMBLY
3 602990 1 LS FUEL TANK ASSEMBLY
4 000323 14 CLIP, HOSE CLAMP
5 015818 131" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
6 745059 1 FUEL VALVE 3-WAY
7 712919 10 FW 0.406X1.00X.12 HD ZN
8 055822 10 CS .375-16X0.75 HX G5 ZN
9 034280 7 CS .312-18X0.750HXG5
10 768523 14 FW 0.343SAE
11 043570 3 CLIP - HOSE - SINGLE(FS)
12 034272 7 NT .312-18HXG5
13 603025 1 TEE, 1/4x1/4x3/16
14 602982 2 CARBON CANISTER, 9 GAL.
15 602980 4 CLAMP, CUSHIONED 3.0"
Fuel System with Carbon Canister—S/N PRIOR TO 12022042 (Multi-Page)
Hustler X-ONE Parts Manual
Tue May 19 17:14:58 UTC 2020 6.1-9
