HUSTLER X-ONE 931774 User Manual

Comments for Page: 60" Side Discharge - Deck Belt, Discharge Chute, Pulley Covers & Blades
1. Do not torque the nut; the discharge chute must pivot freely.
2. Torque to 118 ft-lbs.
3. Torque to 10 ft-lbs.
4. 781872 is used on mowers S/N 12092657 & higher.
5. 601983 is used on mowers S/N prior to 12092657.
Item Part No. Qty Name
1 112933 1 COVER, PULLEY RH 60"
2 112934 1 COVER, PULLEY LH 60"
3 792002 4 KNOB,5/16-18 X 3/4"MALE
4 602988 1 DECK BELT
5 602891 1 CHUTE, DISCHARGE LG
6 602435 1 SPRING, TORSION
7 602432 1 PIN, CHUTE
8 086660 7 NT .375-16NLG8
9 113563 1 BACKING PLATE W/A
10 602817 1 RUBBER BUMPER
11 079210 2 FW 0.344X1.0X0.06 ZN
12 064014 2 CS .312-18X0.875HXG5
13 767954 6 FW 0.379X.82X.06 HD ZN
14 113180 1 WALL, INNER ADJ RH 60"
15 025395 6 CB .375-16X 1.00 G5 ZN
16 113179 1 WALL, INNER ADJ LH 60"
17 794685 3 BLADE, F20.50"-H-F-CW
Not Shown 602771 3 BLADE, F20.50" EHN-F-CW
Not Shown 793794 3 BLADE,20.50"-L-F-CW
Not Shown 794214 3 BLADE,20.50"-MUL-F-CW
Not Shown 794230 3 BLADE,20.50"GAT-F-CW
18 782474 3 CW .678 X 2.250 X .187
19 781872 3 CS .625-11X1.250HXG5
Not Shown 601983 3 CS .625-11 X 2.25 HXG5ZN
60" Side Discharge - Deck Belt, Discharge Chute, Pulley Covers & Blades
Hustler X-ONE Parts Manual
Tue May 19 17:15:48 UTC 2020 8.4-4
