HUSTLER X-ONE User Manual

114565_0112 3-11
Figure 3-14
2
3
6
8
7
1
9
7
8
4
5
8
7
8
9
48" DECK
54"/60" DECK
INDEX
NO.
PART
NO.
DESCRIPTION
1 114323 WEIGHT LOCK PLATE
2 792002 KNOB 5/16-18 X 3/4"
3 114327
114317
WEIGHT MOUNT (X-ONE)
WEIGHT MOUNT (SUPER Z)
4 781880 BUMPER
5 025395 CB .375-16 X 1.00 G5 ZNY
6 603207 WEIGHT
7 086660 NT .375-16 HXZY NL
8 767954 FW .406 X .812 X .060 SAE
9 603339
603340
UB .375-16 X 2.00 X 3.00 SQ (X-ONE)
UB .375-16 X 2.00 X 4.00 SQ
(
SUPER Z
)
Weight Assembly
Locate holes and cut
the step tread here
Locate holes and cut
the step tread here
