114565_0112 6-3
48" Deck Adapter
NOTES:
1. Use existing parts and hardware.
INDEX NO. PART NO. QTY. DESCRIPTION
1 603213 1 BLOWER OUTLET TUBE
2 114066 1 OUTLET ADAPTER
3 025395 6 CB .375-16 X 1.00 G5 ZNY
4 767954 12 FW .406 X .812 X .060 SAE
5 054502 7 NT .375-16 HX GRD 5 ZNY
6 036244 3 CS .375-16 X 1.000 HX G5
7 114194 1 BLOWER MOUNT
8 551034 1 48" BLOWER BELT COVER W/ DECALS
9 601624 1 DISCHARGE CHUTE DECAL
10 601837 1 DECK DANGERS DECAL
11 603318 1 BELT, A 97.0" EL
12 017616 1 CS .500-13 X 1.750 HX G5
13 752386 1 CW .515 X 2.25 X .204 BLK
14 603309 1 48" DOUBLE PULLEY
15 114388 1 48" BELT COVER BRACKET
16 601069 1 CN .312-18 X .200 MAX THK
17 792002 1 KNOB 5/16-18 X 3/4"
18 114068 1 BLOWER BAFFLE, 48"
19 114359 1 RS 48" BLOWOUT BAFFLE
20 086660 2 NT .375-16 HXZY NL
