114565_0112 6-9
60" SZ Deck Adapter
NOTES:
1. Use existing parts and hardware.
INDEX NO. PART NO. QTY. DESCRIPTION
1 603324 1 BLOWER OUTLET TUBE
2 025395 7 CB .375-16 X 1.00 G5 ZNY
3 114066 1 OUTLET ADAPTER
4 767954 13 FW .406 X .812 X .060 SAE
5 054502 7 NT .375-16 HX GRD 5 ZNY
6 551305 1 CENTER DRIVE COVER (WITH DECALS)
7 601624 1 DISCHARGE CHUTE DECAL
8 601837 1 DECK DANGERS DECAL
9 792002 1 KNOB 5/16-18 X 3/4"
10 603806 1 110.5" EL A-SEC BELT
11 008573 1 CS .500-13 X 2.500 HX G5
12 752386 1 CW .515 X 2.25 X .204 BLK
13 602914 1 DOUBLE PULLEY
14 045765 1 FW 1.030 X 1.500 X .134 ZN
15 113118 1 BLOWER MOUNT
16 036244 3 CS .375-16 X 1.000 HX G5
17 115665 1 RIGID LINK
18 601069 1 CN .312-18 X .200 MAX THK
19 115773 1 CENTER DRIVE BRACKET
20 113127 1 BLOWER BAFFLE
21 114361 1 RS BLOWOUT BAFFLE
22 086660 3 NT .375-16 HXZY NL
