114565_0112 6-15
Blower
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 N/A 1 BLOWER HOUSING (NOT SOLD SEPARATELY)
2 322529 1 KEY .187 SQ X .750 LONG
3 602912 1 PULLEY
4 036244 3 CS .375-16 X 1.000 HX G5
5 712919 1 FW .406 X 1.00 X.12 HRD Z
6 058776 10 NT .312-18 HXZY NL
7 768523 11 FW .343 X .687 X .051/.080H
8 602661 2 BEARING FLANGE 1.00"
9 016253 10 CB .312-18 X .750 FUL ZN
10 113120 1 BLOWER IMPELLER
11 016972 2 NT .625-11 HX G5 ZNYC
12 028118 4 FW .625 X 1.00 X .134 ZNYC
13 600296 3 DECK IDLER SPACER
14 791566 1 IDLER PULLEY 3.25" OD X .6
15 016642 2 CS .625-11 X 2.00 HX G5 Z
16 781567 1 NT .500-13 HX G8 ZY NL
17 767962 2 FW .531 X 1.063 X .090 SAE
18 602913 1 V-IDLER PULLEY
19 770867 2 BUSHING
20 109549 1 BUSHING
21 036384 1 SPRING 1/4 COIL PL 1.23
22 113406 1 BLOWER IDLER ARM
23 008573 1 CS .500-13X2.500 HX G5
To Next Page
