114565_0112 6-17
Blower
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
24 114337 1 BEARING COVER
25 113119 1 BLOWER COVER
26 799130 8 CS .312-18 X .500 HXFL
27 792002 1 KNOB 5/16-18 X 3/4"
28 036236 1 CS .312-18 X 1.000 HX G5
29 114338 1 DRIVEN PULLEY COVER
30 601069 2 CN .312-18 X .200 MAX THK
31 086660 5 NT .375-16 HXZY NL
32 073858 2 FW .406 X .750 X .250 ZNYC
33 602674 1 CB .375-16 X 6.00 STD
34 602757 1 BLOWER DANGERS DECAL
35 N/A 1 TURF PRODUCTS SERIAL NO. PLATE
36 704718 2 FW .406 X .688 X .060 ZNYC
37 602435 1 TORSION SPRING
38 550995 1 BLOWER LID (WITH DECALS)
39 602758 1 EYES/EARS/FOOT DECAL
40 767954 3 FW .406 X .812 X .060 SAE
41 603191 1 BLOWER CHUTE INLET
42 025395 3 CB .375-16 X 1.00 G5 ZNY
43 113128 1 BLOWER INLET BAFFLE
44 054502 1 NT .375-16 HX GRD 5 ZNY
45 076422 2 FW .406 X 1.000 X .06 ZNYC
46 774919 2 CS .375-16 X .500 SOC BH
47 550996 1 BLOWERASSEMBLY
To Next Page
