114565_0112 6-21
Catcher Frame
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
36 603358 2 LID LATCH SPRING
37 063297 4 SB .375 X .500 SH .312-18
38 073858 1 FW .406 X .750 X .250 ZNYC
39 113794 1 LID CATCH
40 114399 1 LID INSERT
