114565_0112 6-27
Catcher Frame Adapter— X-ONE
NOTES:
INDEX NO. PART NO. QTY. DESCRIPTION
1 114323 1 WEIGHT LOCK PLATE
2 792002 2 KNOB 5/16-18 X 3/4"
3 114327 1 WEIGHT MOUNT
4 781880 8 BUMPER
5 025395 6 CB .375-16 X 1.00 G5 ZNY
6 603207 4 WEIGHT
7 086660 6 NT .375-16 HXZY NL
8 767954 14 FW .406 X .812 X .060 SAE
9 603339 2 UB .375-16 X 2.00 X 3.00 SQ
10 602323 1 STEP TREAD
11 054502 4 NT .375-16 HX G5 ZN
12 114661 1 AUX WEIGHT PLATE, 10 LB.
