HUSTLER Z XR7 - Page 29

106567 4/07 5-3
Kawasaki Engine Installation
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 777656 777656 1 KAWASAKI 23 HP ENGINE
782318 782318 1 KAWASAKI 25 HP ENGINE (FH721V, 3600 RMP)
2 058776 058776 4 NT .312-18 HXZY NL
3 768523 768523 22 FW .343 X .687 X .051/.080 HD ZN/YL
4 029876 029876 1 LW .312 INT-EXT TOOTH ZN
5 792762 792762 1 BATTERY CABLE
6 768515 768515 5 FW .281 X .625 X .051/.080 HD ZN/YL
7 024927 024927 3 NT .250-20 HX GR.5 ZN
8 799312 799312 1 WIRE HARNESS ADAPTER
9 799320 799320 1 COMMON WIRE HARNESS
10 044255 044255 1 NT #10-32 HX ZN
11 030817 030817 1 STARTER SOLENOID
12 055947 055947 2 CS .250-20 X .500 HX G5 ZN
13 792192 792192 1 STARTER RELAY GROUND WIRE
14 771428 771428 1 RED BATTERY CABLE BOOT
15 050161 050161 4 CS .312-18 X 1.75 HX G5
16 786673 786673 1 DONALDSON AIR CLEANER CAP
17 057661 057661 3 HOSE CLAMP
18 788943 788943 1 AIR FILTER INDICATOR
19 785741 785741 1 MOUNTING BAND
20 034272 034272 6 NT .312-18 HX G5 ZN
21 782763 782763 1 AIR CLEANER
22 366443 366443 1 REMOTE AIR CLEAN MOUNT BRACKET
23 036236 036236 6 CS .312-18 X 1.00 HX G5 ZNYC
24 786038 786038 1 REMOTE AIR FILTER HOSE
25 796524 796524 1 OIL DRAIN M20 X 2.5 VALVE
26 350371 350371 1 MUFFLER GUARD
27 349704 349704 1 ENGINE CAGE MOUNT PLATE
28 767962 767962 6 FW .531 X 1.063 X .090 SAE HD ZN
29 016527 016527 6 CS .500-13 X 1.00 HX G5 ZN
30 064006 064006 2 CS .312-18 X .625 HX G5 ZN
31 781732 781732 1 MUFFLER MANIFOLD
32 781724 781724 1 MUFFLER
33 720177 720177 2 CS M 8-1.25 X 20 10.9 HXFL ZN
34 782649 782649 1 KAW (23) EXHAUST PIPE CLAMP
35 782664 782664 4 NT M8-1.25 HX STAINLESS STEEL
36 017004 017004 4 LW .312 MED SPRING ZN
37 360693 360693 1 HEAT SHIELD
38 780841 780841 2 KAW (23) MUFFLER GASKET
39 789131 789131 1 HUSTLER Z FAN CONNECTOR CAP
