Front Wheel Assembly
NOTES:
1. Apply grease to zerks.
2. Torque to 100 ft.-lbs.
3. Assemble with extended inner race toward item 5 (387035 Spacer, 1.07
x 1.312 x 2.793).
INDEX
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 705954 705954 2 CS .500-13 X 1.25 HX G5 ZN
2 344267 344267 2 FW .510 X 2.15 X .187 SPL ZN
3 712976 712976 2 FW .531X 1.375X.125 ZNY
4 784223 784223 4 BEARING W/O COLLAR
5 387035 387035 2 SPACER, 1.07 X 1.312 X 2.793
6 045765 045765 2 FW 1.030 X 1.500 X.134 ZN
7 349266 349266 2 FORK
8 041475 041475 2 CS .750-10 X 9.50 HX ZN
9 025296 025296 4 FW .760 X 1.625 X .08 ZN
10 061101 061101 2 NT .750-10 HX NL ZN
11 747782 747782 2 WHEEL & TIRE ASSY
789537 N/A 2 OPTIONAL SEMI-PNEUMATIC WHEEL/TIRE ASSEMBLY
To Next Page
