HUSTLER Z XR7 - Page 57

106567 4/07 7-7
60" Side Discharge Deck Assembly
NOTES:
1. Do not torque, Item 2 (798694 Discharge Chute) must pivot freely.
2. Includes items 7, 8, 9, and 10.
3. Service part deck includes decals (see ’’60" Deck Decals” in on page -
5 for listing of decals).
4. For optional anti-scalp wheels order:
INDEX NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY. DESCRIPTION
1 547745 314021 1 60" DECK CRATED
2 798694 798694 1 RUBBER CHUTE ASSEMBLY
3 052860 052860 8 CS .375-16 X 1.25 HX G5
4 767954 767954 30 FW .406 X .812 X .060 SAE HD ZN
5 086660 086660 24 NT .375-16 HX LK NY
6 103010 103010 1 DISCHARGE CHUTE MOUNT BRACKET
7 781708 N/A 6 CS .500-13 X 4.25 HX G5 ZN
8 767962 N/A 12 FW .531 X 1.063 X .090 SAE HD ZN
9 031997 N/A 6 ANTI-SCALP WHEEL
10 053199 N/A 6 NT .500-13 HX JAM ZN
11 781567 781567 6 NT .50-13 HX LK NY
12 808485 808485 4 5/16-18 THREAD RIVET NUT
13 103184 103184 2 REAR ANTI-SCALP BRACKET
14 005116 005116 4 CS .375-16 X 1.375 HX G5 ZNYC
15 314104 314104 1 PUSHER
16 015495 015495 2 STRAIGHT GREASE FITTING
17 808493 808493 2 3/8-16 THREAD RIVET NUT
788166 788166 4 ANTI SCALP WHEEL ASSY
INDEX NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY. DESCRIPTION
21 788166 788166 2 ANTI-SCALP WHEEL ASSEMBLY
22 781567 781567 2 NT .500-13 H8ZY NL
3
2
2
