106567 4/07 8-3
Deck Installation
NOTES:
1. 66" Deck installation is shown, 54" and 60" Deck installations are similar.
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY DESCRIPTION
1 055749 055749 4 CS .437-14 X 1.750 HX G5 ZN
2 061101 061101 2 NT .750-10 HX NL ZN
3 025296 025296 4 FW .760 X 1.625 X.08 ZN
4 051169 051169 2 CS .750-10 X 3.000 HX G5 ZN
5 704643 704643 8 NT .437-14 HX FLG ZN
