Spare parts NO Spare parts
1 Top cover 39 Clip
2 Ambient temp. sensor 40 Terminal board Bracket
3 Ambient temp. sensor clip 41 Water pump 3-position terminal
4 Back grill 42 Terminal cover
5 Evaporator 43 Rubber fixing block
6 Coil temp. sensor 44 Gas colleting piping
7 Temp. sensor clip 45 Back panel
8 Sensor casing pipe 46 Back gas piping
9 Distribution piping 47 Low pressure switch
10 Isolation panel 48 Pipe (4-way valve to Gas collect )
11 Reactor 49 Exhaust pipe
12 Pillar 50 Pipe (4-way valve to exchanger)
13 Upper frame 51 4-way valve
14 Fan motor bracket 52 High pressure switch
15 Clip 53 Exhaust temp. sensor
16 Evaporator Heating Belt 54 Pipe ( Liquid reservoir to EEV )
17 Bracket for panel 55 Pipe ( Filter to Liquid reservoir )
18 Fan motor 56 Pipe (EEV to Distribution )
19 Fan blade 57 EEV
20 DC motor casing tube 58 Filter
21 Controller box 59 Pipe (Titanium exchanger to filter )
22 Right panel 60 Water flow switch
23 Ventilation grid 61 Water outlet temp. sensor
24 Front panel 62 Water outlet temp. sensor clip
25 Water proof box 63 Titanium heat exchanger
26 Controller 64 Water connection
27 N/A 65 Blue rubber ring
28 N/A 66 O' ring
29 Compressor 67 Water inlet temp. sensor
30 Anti-vibration hammer 68 Drainage plug
31 Liquid reservoir 69 Red rubber ring
32 Compressor heating belt 70 Sealing ring for water flow switch
33 Base tray 71 PCB
34 Handle 72 N/A
35 Terminal board 73 Board
36 Right panel 74 Electric box cover
37 Power supply 3-position terminal 75 Electric box
38 Pressure gauge
