12.06.7 UTOWE170-C-4
Page II
Data sheet UTOWE170-C-4
Fig.: 1 Data sheet
Total length: 5,304.79 mm
Total width: 662.94 mm
Tube: Steel tube 127 mm O.D. X .6,350 mm WALL
Weight: 181.6 Kg
Tires: 2.4 bar
Operating temperature: - 20° C to + 60° C / (- 4° F to + 140° F)
Tow eye: revolving with shock absorber
Tow head: not revolving
Shear pin: part no 0432-0001-000, 0432-0002-000 and
0432-0003-000 for EMB. 170 - 195
Suitable for the following aircraft types:
E170 thru E195
