Valve clearance (cold):
Basic bearing clearance
Conrod bearing clearance
Control times for 1mm valve lift
Outlet opening
Outlet closing
Inlet opening
Inlet closing
Valve diameter
Valve seat angle
Correction angle 1
Correction angle 1
Valve seat width
Starter
Turbo
Outlet: 0.18 – 0.25 mm
Inlet: 0.08 – 0.15 mm
0.03 – 0.05 mm
0.03 – 0.05 mm
52° aBDC
2° bTDC
14° bBTDC
50° aBDC
EV: 29.5 mm
AV: 32.5 mm
45°
30°
60°
Inlet: 1.1 mm
Integrated starter 800 W
Ratio: 33:1
Free wheel
