Triple Motion Security Light
INSTALLATION INSTRUCTIONS
1. MOUNTING BRACKET 3. INSTALL LAMP BODY
2. CONNECT WIRE AND LAMP BODY
4. BLOCKING LAMP BODY AND
MAKE IT WATERPROOF
AFTER INSTALLING YOUR MOTION ACTIVATED LIGHT, YOU ARE READY TO SET/AIM THE MOTION SENSOR. MAKE SURE THE WALL
SWITHCH IS IN THE ON POSITION.
1) Switch the TIMES/TEST switch in the TEST position to disable the photocell and allow light to come on during daylight hours.
2) Rotate the RANGE knob fully clockwise to maximum RANGE.
3) Aim the MOTION SENSOR HEAD level at least 10 Degrees downward an across the traffic pattern you want to detect.
4) Test Motion detection zone by walking across the pattern in the targeted coverage area. A red LED indicator light in the motion head will
flash when motion is detected and the lights will come on for approximately (40 seconds). Move to a different spot in the area to be tested
and stop all motion for about 8 seconds. The lights should turn off. Start walking again to see if your motion is detected in the new spot. Move
further away to check the distance and adjust range to your desired location.
5) SET ON TIME: When you are satisfied with the area of coverage, rotate the TIME/TEST switch to the opposite end to take the motion
sensor out of the TEST mode. Now you can rotate the switch to set the ON time. The TIME setting switch will let you adjust the time that the
light will stay on after motion is detected from approximately 1 to 10 minutes.
6) MANUAL OVERRRIDE METHOR: To disable the motion and keep the light continuously on in the darkness, flip the wall switch off and back
on within 3 seconds. If you leave the light on all night, it will automatically turn off at dawn and reset to Security Mode.
SET/AIM THE MOTION SENSOR
PLEASE READ CAREFULLY AND SAVE THESE INSTRUCTIONS, AS YOU MAY NEED THEM AT A LATER DATE.
