Neutrik NC3MXX-B or -BAG (male)
This information is given for reference and to guide
you in connecting your DIY-kit in the correct way.
Do not modify the internal wiring of the kit other
than specified in the instructions.
Pin 1: Shield
Pin 3: Negative (- or cold)
Pinout:
Pin 2: Positive (+ or hot)
Neutrik NC3FXX-B or -BAG (female)
Balanced XLR connection:
Advanced system information
Output Impedance:
(weight for the total assembled kit)
Distortion:
0.02% @ 20Hz < f < 20kHz Pout<PR/2
External size (WxHxD): 200 x 79 x 280 mm
Dimensions and weight
UcD700 mono kit: 3.04 kg
(size incl feet, excl connectors)
Input Impedance:
100kΩ Either input to ground
Power Bandwidth: 20 - 35kHz
Frequency Response: 10Hz - 50kHz
Operation:
20mΩ f < 1kHz
Performance:
150mΩ f < 20kHz
For more detailed information please refer to the
datasheet of each individual product on our
website.
Voltage Gain: 25.5 - 26.5dB
Load impedance: min 1Ω
Source impedance: max 7kΩ
Input power:
Connector: 3-pin IEC 250Vac, 10A male.
700W 4Ω @ 2.65V
High Line input voltage: 180 - 264Vac**
Input sensitivity:
1
Line input power
Technology:
UcD®
Channels:
Mono XLR
Output:
Bindingpost
Low Line input voltage: 90 - 132Vac*/**
Depending on load, 1350W max
Input:
Line input frequency: 47 - 63 Hz
Output power in 4 1% THD+N :Ω @
700W
360W
** Operation beyond these limits may
Output power in 8 1% THD+N :Ω @
* With low line jumper placed
result in irreversible damage
System information UcD700 mono kit
2x
❺
