Service Manual
No. Ref. No. Part No. Description
1494 X100 3701019250030 TCXO (19.2MHz)
1495 X302 3701019250040 Temperature compensated crystal oscillator (19.2MHz)
1496 X375 3701327610060 Crystal
1497 F900 4099000000050 Fuse
1498 J400 5201020000020 Connector
1499 J404 5206040200010 FFC connector
1500 PCB 41MD7801000F0 PCB
1501 6201928000000 VCO shielding mask
1502 6202010000000 APC shielding mask
1503 L819 3233099470000 47nH
1504 C752 3101074750000 4.7UF
1505 C718 3101051050160 1uF
1506 C237 3101054740020 0.47uF
1507 Q400 3413001000010 PNP transistor
1508 D900 3302060000000 Zener diode
1509 Q921 3404999000020 NPN transistor
1510 U232 3612044000010 Memory
1511 U327 3607082000040 Logic IC
1512 U328 3607082000040 Logic IC
1513 R6121 3001053600000 36Ω
1514 R6124 3001051510000 150Ω
1515 R6125 3001051510000 150Ω
1516 Z6100 3802733540030 Crystal filter
156
