Your vehicle at a glance
102
OGD071002
❈ The actual engine compartment in the vehicle may differ from the illustration.
1. Engine oil filler cap ............................7-47
2. Engine oil dipstick..............................7-46
3. Brake/clutch fluid reservoir ................7-53
4. Positive battery terminal ....................7-62
5. Negative battery terminal ..................7-62
6. Fuse box............................................7-80
7. Air cleaner ........................................7-56
8. Radiator cap ......................................7-51
9. Engine coolant reservoir....................7-50
10. Windshield washer fluid reservoir....7-54
11. Fuel filter ........................................7-55
■
Diesel engine (1.6L)
