7-58
Maintenance
Fuse Name Fuse Rating Protected Component
MODULE 5 7.5A
ATM Shift Lever IND., Electro Chromic Mirror, AMP, A/V & Navigation Head Unit, A/C Control Module,
Front Air Ventilation Seat Module, Front Seat Warmer Module
MODULE 3 7.5A Stop Lamp Switch, BCM, ATM Shift Lever
SUNROOF 20A Sunroof Unit
TAIL GATE
OPEN
10A Tail Gate Relay
P/WINDOW
LH
25A Power Window LH Relay, Driver Safety Power Window Module
MULTI MEDIA 15A A/V & Navigation Head Unit
P/WINDOW
RH
25A Power Window RH Relay, Passenger Safety Power Window Module
P/SEAT (DRV) 25A Driver Seat Manual Switch
P/SEAT
(PASS)
25A Passenger Seat Manual Switch
MODULE 4 7.5A
Blind-Spot Collision Warning Unit LH/RH, Active Air Flap, BCM, Parking Distance Warning Buzzer,
Lane Keeping Assist Unit (Line), 4WD ECM
PDM3 7.5A Smart Key Control Module, Immobilizer Module
POWER
OUTLET 2
20A ICM Relay Box(Power Outlet Relay)
Instrument panel fuse panel
To Next Page
