2
A1
Head bar of the frame (with bearings)
x1 x1 x1
A2
Foot bar of the frame
x1 x1 x1
B
Center frame support with slat holes
x2 x2 x2
C
Center frame supports
x4 x4 x4
D
Long center frame support
x1 x1 x1
E
Left and right frame bars
x2 x2 x2
F
Flat bars
x2 x2 x2
G
Pistons (non locking)
Single: 90kg, Double: 90kg, Queen: 110kg
x2 x2 x2
H
Mattress Supports
x2 x2 x2
I
Mounting plates (left and right)
x2 x2 x2
J
Saddle locking plates
x2 x2 x2
K
Brackets to attach wall bed to wall
x3 x3 x3
L
Door brackets
x8 x16 x16
M
Legs (left and right)
x2 x2 x2
N
Tube (for attaching legs)
x1 x1 x1
O
Slats
x36 x36 x38
P
Slat caps
x36 x36 x38
Q
Double slat caps
x18 x18 x19
HARDWARE
