IACER Srl 16 MNPG53-07
We recommend to use professional solenoids couple (which guarantee
high performance and greater field strength and tissue penetration.) if you
need an higher field intensity or in case of tissue treatment in depth or still
in presence of rigid bandages or braces.
Setup and programs instructions
Connections and power on
For proper installation of the device, we recommend to carefully read and
follow the below steps:
1. connect the applicator (or the applicators) to the device by
connecting applicator cable to one of the two plugs (CH1-CH2)
placed on the device upper side;
2. connect the power supply cable to the main, then connect the
power supply plug to the circular connector placed on the device
upper side, near to the ON/OFF switch;
3. connect the power supply plug to the main socket (110-230VAC,
50-60 Hz);
4. Move the ON/OFF switch, placed on device upper side, to the ON
position: I-TECH logo and programs menu will be displayed on
screen.
ATTENTION! To keep the device protected from penetration of solid
objects, powders and liquids, it is recommended to use it ALWAYS
INSERTED inside the envelope of protection!
Main menu
The MAG2000 PLUS device is equipped with 35 programs with preset and
user-modifiable values according to your needs. The first 20 programs are
associated with the treatment of specific pathologies with preset
parameters recommended by IACER, while the following 15 have only the
preset working frequency, leaving the user the freedom to choose the
duration and the cycles of sessions.The device has also the possibility to
store 10 user memories (USER01-USER10) to fully customizable
parameters.
Therapy duration values are recommended by I.A.C.E.R. S.r.l. however the
user can adjust the time as he prefers. Also, for each seating cycle (column
Treatment cycles of the table List of programs above) the manufacturer
