2.1.6. Overview Menu Section B
The table below gives an overview of the menu structure. The two menu levels are clearly indicated
by an arrow followed by a submenu. The values shown are only intended as examples of display
texts.
Menu Structure B
Display Functions Description
Operation mode - GRID
Displays present inverter operation mode. See operation mode definitions in
chapter 2.
PV configuration - INDIVIDUAL
Shows the status of the automatic PV configuration test and the results
found.
Event: Mod. - U-GRID DCAC
If the inverter is not connected to the grid because of a failure, the red LED
starts flashing, and the reason for the failure is shown here.
Language - ENGLISH View and choose display language. Does not affect any other settings.
Grid voltage - 234 V Displays the present grid AC voltage.
Grid current - 1.2 A Displays the present current flow to the grid.
Grid frequency - 49.9 Hz Displays the present grid frequency.
Grid impedance - 0.1 ohm Displays the present grid impedance.
PV voltage - Press OK to view Press OK to access submenu for recorded events.
↳
Submenu
PV voltage no. 1 - 123 V Present voltage at PV input 1 (upper position in inverter).
PV voltage no. 2 - 124 V Present voltage at PV input 2 (second position in inverter)*.
PV voltage no. 3 - 124 V Present voltage at PV input 3 (third position in inverter)*.
PV current - PRESS OK to view Press OK to access submenu for recorded events.
↳
Submenu
PV current no. 1 - 1.2 A Present current at PV input 1 (upper position in inverter).
PV current no. 2 - 1.2 A Present current at PV input 2 (second position in inverter)*.
PV current no. 3 - 1.2 A Present current at PV input 3 (third position in inverter)*.
Maximum values - Press OK to view Press OK to access submenu for recorded events.
↳
Submenu
AC out: 3707 W - 3.2 A 235 V
Maximum values recorded at AC output since last resetting of max. value
memory. (reset)
DC1 in: 1578 W** - 1.8 A 203 V
Maximum values recorded at DC1 input since last resetting of max. value
memory. (reset).
DC2 in: 1609 W** - 1.9 A 198 V
Maximum values recorded at DC2* input since last resetting of max. value
memory. (reset)
DC3 in: 1609 W** - 1.9 A 198 V
Maximum values recorded at DC3* input since last resetting of max. value
memory. (reset)
Table 2.3: Overview Menu Structure B
*) The PV2 and PV3 menus are only displayed in inverters equipped with two or three inputs.
**) The maximum values for PV power may reach more than 2000 W in inverters where the inputs are connected in parallel.
This is normal.
2. Function Description
C00410346-02 7
