ENGLISH
IBERITAL
86 INSTALLATION AND OPERATION MANUAL
the display will then show:
Coffees total
Total reset
NOTE
Erasing the total coffee count does not erase the reading for the litres of water consumed. To eliminate
the alarm for CHANGE/REPLACE FILTER for the litres of water consumed, see the section WATER FILTER
CHANGE/REPLACEMENT ALARM.
- Press the MENU button and the display will show:
zzzzz GR:
xxxxxxxx
zzzzz:1 espresso, 1 coffee, etc.
GR: Group 1/2/3
xxxxxxx: Nº of coffees
showing the number of coffees by dose and by group.
Continuing to press the MENU button will show the number of coffees by selection.
2.9.3.1.2. Technical menu display
Remember that to access the Technical MENU, the display must be in the OFF position (the display will show the word
OFF). If it is in the ON position (the display will show the name entered), in order to access the OFF mode, press the I/O
(ON/OFF).
Once in OFF mode, in order to access the technical menu, you must press the the MENU button for around 10-15
seconds (based on the display used) and go into technical level programming mode.
