Table 87. Supported PDU power cords for POWER9 systems (continued)
Featur
e code
(FC)
Description
Voltage
Amperage
Phase
Length
Wall plug
IBM
shipped
plug
View of
plug
Matched
female
connector
(on cord)
Matched
female
wall
receptacle
(on wall)
IBM part
number
Countries
6654
Power cord, PDU to
wall
200 - 208 V ac or
240 V ac
30 A plug (24 A
derated)
Single phase
4.3 m (14 ft)
NEMA L6-30
Plug type
NEMA
L6-30P
Receptacle
type NEMA
L6-30R
39M5416 United
States,
Canada,
Latin
America,
Japan, and
Taiwan
6655
Power cord, PDU to
wall
200 - 208 V ac or
240 V ac
30 A plug (24 A
derated)
Single phase
4.3 m (14 ft)
RS 3750DP
(Watertight)
39M5418 United
States,
Canada,
Latin
America,
Japan, and
Taiwan
6656
Power cord, PDU to
wall
230 V ac
32 A
Single phase
4.3 m (14 ft)
IEC 309, P+N+G
Plug type
60309
Connector
type
60309
Receptacle
type 60309
39M5414 Europe,
Middle East,
Africa
(EMEA)
Site and hardware planning 93
