Table 65. Dimensions for rack (continued)
Rack
configuration
Width Depth Height
1
Weight
(empty)
Weight
(maximum
configuration)
EIA unit
capacity
Rack with FC
ERG0 rack
extension and
standard front
and rear doors
644 mm (25.4
in.)
1303 mm (51.3
in.)
2015 mm (79.3
in.)
315 kg (694 lb) N/A N/A
Notes:
1. The top 6U of the rack can be temporarily detached at the client site to make it easier to move the rack through
doors or elevators. The top 6U is then reattached to the rack frame to provide the full 42U rack capacity. The
rack is approximately 28 cm (11 in.) shorter when the top is removed. For more information about removing the
top cover, see Removing the rack top cover. The weight of the top cover is approximately 29 kg (63 lbs).
2. For more information about rack weight distribution and floor loading, see 7014-T00, 7014-T42, and 0553 rack
weight distribution and floor loading.
Table 66. Dimensions for doors
Door model Width Height Depth Weight
Standard front door 639 mm (25.2 in.) 1946 mm (76.6 in.) 56 mm (2.3 in.) 16 kg (34 lb)
Standard rear door 639 mm (25.2 in.) 1946 mm (76.6 in.) 26 mm (1.0 in.) 13 kg (27 lb)
With acoustic foam:
16 kg (34 lb)
Standard side covers
(each)
10 mm (.4 in.) 1740 mm (68.5 in.) 1042 mm (41.0 in.) 18 lbs 8.25 kg(18 lb)
FC 6084 front door
(OEM)
639 mm (25.2 in.) 1946 mm (76.6 in.) 56 mm (2.3 in.) 16 kg (34 lb)
FC 6069 front door,
high perforation
639 mm (25.2 in.) 1946 mm (76.6 in.) 56 mm (2.3 in.) 16 kg (34 lb)
FC ERG7 front door
770/780 high
perforation
639 mm (25.2 in.) 1946 mm (76.6 in.) 134 mm (5.3 in.) 17 kg (37 lb)
FC 6249 acoustic
doors, front and rear
639 mm (25.2 in.)
each
1946 mm (76.6 in.)
each
198 mm (7.8 in.) each 13.6 kg (30 lb) each
FC 6250 high end
appearance front door
639 mm (25.2 in.)
each
1946 mm (76.6 in.)
each
90 mm (3.5 in.)
FC ERGB acoustic
door, front only
639 mm (25.2 in.) 1946 mm (76.6 in.) 198 mm (7.8 in.) 13.6 kg (30 lb)
FC 6238 high end
appearance side
covers
10 mm (.4 in.) 1740 mm (68.5 in.) 1042 mm (41.0 in.) 8.5 kg (18 lb)
FC 6858 heat
exchanger rear door
639 mm (25.2 in.) 1946 mm (76.6 in.) 147 mm (5.8 in.) Empty: 29.9 kg (66 lb)
Full: 35.6 kg (78.5 lb)
FC ERG0 8-inch rack
extension
647 mm (25.4 in.) 1957 mm (77.1 in.) 203 mm (8.0 in.) 27 kg (58.0 lb)
FC ERG8 ballast
weight specify code
1
N/A N/A N/A 52.1 kg (115 lb)
1
When model 9080-MHE, 9080-MME, 9119-MHE, and 9119-MME servers are ordered with FC ER16 to reserve rack
space for future system nodes, FC ERG8 is automatically added to the order.
42 Site and hardware planning
