IBM 900 - Page 105

Male
Male
Channel
Interface-in
Cable
Channel
Interface-out
Cable
Female
Female
Gray Black
BUS-in BUS-out
TAG-in TAG-out
Black
Black
Channel in Channel out
From Host
Gray
Gray
V-Cable
Black Gray
Figure 3-13. Cabling to IBM multiaccess enclosure in the Middle of the Channel
Chapter 3. Multiaccess Enclosure Problem Determination 3-35
