Prerequisite Before some FRU Exchanging
1 Ask the customer to stop the traffic on all the Multiaccess Enclosure.
2 On the Service Processor select the 3746/9x0 Menu.
3 Click on the Multiaccess Enclosure (MAE) Management.
4 Double click on the Perform Maintenance on MAE.
5 The following window is displayed:
Click on Yes.
6 The following window is displayed:
Click on OK.
7 You should first received an alarm message saying: "MAE Concurrent
Maintenance in Progress".
8 Click on OK.
9 In the following table, find the FRU you want to exchange and go to the
procedure indicated.
Note: Be aware that the MAE will be restarted automatically after 40 minutes.
4-2 3746-9X0: MAE Installation and Maintenance
