Exchanging the PCMCIA Card
Attention
The PCMCIA card is hot pluggable, but the customer traffic must be stopped on
the multiaccess enclosure.
1 Remove the cable from the PCMCIA Card.
YY
Y
Y
YY
Y
Y
Y
Y
Y
AB 1
5
2
6
3
7
4
8
Cable Unlocking Detail
2 Press the upper button to remove the PCMCIA card from the multiaccess
enclosure.
Button
Detail of PCMCIA
Card Locking
3 Plug the new PCMCIA card into any slot of the system card of the
multiaccess enclosure.
Chapter 4. Multiaccess Enclosure FRU Exchange 4-35
