Using the Command Line Interface Operational Diagnostics
The following example shows how to access the multiaccess enclosure diagnostics
through the command line interface:
1 Select <1. The Device List > to view a list of installed devices. (Status and
test options for each device are from the Device List page.) The Device
Status and Control panel (similar to the one in Figure 5-23) appears.
Device List
"For more information on each device select from the following list:
Device Location Status
Token Ring Slot 1 Multi-Port Adapter ENABLED
< 1. Token Ring> Slot 1 Port 1 Net # 0 ENABLED
Token Ring Slot 1 Port 2 NOT CONFIGURED
< 2. ATM MMF > Slot 2 Port 1 Net # 1 DISABLED
< 3. ESCON > Slot 3 Single Port Net # 2 ENABLED
< 4. ESCON > Slot 4 Single Port -- NOT CONFIGURED
Some of the devices are note currently available for testing. This can occur
when a test is not available for the device or when the device must be
configured in order to be tested,
Select (1-4 or D=Down B=Back R=Refresh h=Help):
Figure 5-23. Sample of Device List Panel Showing Interfaces
The Device List is the starting point for running a test. It also provides a
check to determine if all of the installed devices are being recognized by the
multiaccess enclosure.
The Device List includes a summary status for each device. The devices
that are testable or that have additional status available can be selected.
Selecting a device will then display the Device Status and Control page for
that device.
The Status displayed for a device may have the following values:
ENABLED Device is enabled for normal operation. For multi-port
devices this means that at least one port is enabled.
ENABLE PENDING Waiting for completion of Enable request.
Special Device is in a special state that is explained on the
Device Status and Control Page.
DISABLED Device is Disabled. Diagnostic testing can now be
performed. For multi-port Devices this means that all
ports are disabled.
DISABLE PENDING Waiting for completion of Disable request.
MESSAGE Select the device to view and respond to the
message.
5-44 3746-9X0: MAE Installation and Maintenance
