6 Select b to see the results of the test.
Screen 1 of 1
Test Results
LIC 287 - ESCON Channel Adapter, Slot 4, Net # 0
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED INACTIVE OK UNKNOWN
The Test Completed with No Errors.
Select ( B=Back ):
If the test completed with no errors, light was detected on the fiber optic
cable.
Screen 1 of 1
Test Results
LIC 287 - ESCON Channel Adapter, Slot 4, Net # 0
Operational Status Diagnostic Status Fault Status Network Connection
NOT CONFIGURED INACTIVE NON-ISOLATED UNKNOWN
No light is being detected on the ESCON adapter in slot 4. Ensure that the
ESCON fiber is connected to an ESCON director or an ESCON channel.
Select ( B=Back ):e
If light was not detected, an error message is displayed, indicating that the
fiber and its connections need to be rechecked.
