10 Enter 1 from the Optical Test in Progress panel to Stop the test.
Screen 1 of 1
Optical Test In Progress
LIC 287 - ESCON Channel Adapter, Slot 4, Net # 0
Operational Status Diagnostic Status Fault Status Network Connection
DISABLED TESTING UNKNOWN UNKNOWN
Do not remove this device while testing.
The green PORT LED should now be flashing on the ESCON channel
adapter in slot 4, indicating that it is transmitting IDLE sequences.
You may now record the power level displayed on the optical power meter
A properly functioning ESCON should have a power level of -21.0dBm or more
(for example -18.0dBm).
Select < 1. Stop > test when you have finished
measuring the signal level.
Select (1 or B=Back R=Refresh H=Help ): 1
11 The following Test Results panel is displayed when you stop the test.
Screen 1 of 1
Test Results
LIC 287 - ESCON Channel Adapter, Slot 4, Net # 0
Operational Status Diagnostic Status Fault Status Network Connection
DISABLED INACTIVE OK UNKNOWN
The Test Completed with No Errors.
Select ( B=Back ):
