Service
Processor
Network Node
Processor-A
Network Node
Processor-B
Modem
LCBB/LCBE
Display
Optical Disk Drive
Figure D-10. Units Installation in the Controller Expansion (SP and NNP Type 6275)
Service
Processor
Modem
Network Node
Processor-A
Network Node
Processor-B
LCBB/LCBE
Multiaccess
Enclosure
Display
✹✹
✹
✹
✹✹
✹
✹
✹
✹
✹
Figure D-11. Units Installation in the Controller Expansion (SP and NNP Type 6275 + MAE)
D-10 3746-9X0: MAE Installation and Maintenance
